Vacuum Die Casting
When excessive air is trapped inside the casting it will cause defects such as internal porosity or blisters on the surface. If normal venting is not sufficient, you can extract it out using vacuum.
Continue Reading
HV1500
Vacuum Unit HV1500
Option of either integral or split type, including operational panel and main valve box. Standard setup includes 2 channels which can be customized to be up to 6 channels as per requirement.
| project | parameter | project | parameter |
| DCM | 4500ton | Vac curve | trigger |
| Movable | - | Tool recipe | 24 |
| Interface | cable/network | Channels | 2xDN25 |
| Pump | 200m3/h | Chinese/English | ● |
| Power consumption | 4KW | Vac test | ● |
| Capacity | 1500L | Pollution test | ● |
| Ultimate vacuum | 0.1mbar | Profile test | ● |
| System vacuum | <10mbar | Channel blowing | individual |
| Compressed air | 6bar | Compatibility | positive valve |
| Air consumption | 550L/min | chill block | |
| Occupied area | 1200×1800mm | pneumanic valve | |
| Weight | 550KG | super vavle | |
| PLC | S71200/1500 | hydralic valve | |
| Touch panel | TP700/900/1200 |
